Stainless Steel Orifice Flange
Application:
Orifice flanges are the equivalent as weld neck flanges or slip on flanges. The differences are that these flanges have additional machining and have radial and tapped holes. This serves as the purpose of meter connections, which helps as jackscrews to provide for the detachment of flanges at the time of replacement of the orifice plate. Orifice flanges are generally used with orifice meters for better performance. This makes easy to measure the flow rates of oil, gas, and other fluids that have been conveyed in a pipeline. The standard assembly of orifice flanges involves gaskets, nuts, bolts, plugs, plates, a pair of flanges, and jacking screws. Jacking screws make removal of the primary flow element easier. When there is a requirement to connect a flow nozzle or an orifice plate, then ASME B16.36 orifice flanges are used instead of standard pipe flanges.
Specification:
PRODUCT NAME | Stainless Steel Orifice flange |
SAMPLE SUPPORT | Yes |
DELIVERY TIME | Depends on Quantity and Other Requirements |
MOQ | 200kg / Depends on Flange Size |
PRICE | The Higher The Quantity, The Cheaper |
SIZE | 1/2"-60"(DN10-DN1500) |
MATERIAL | Carbon steel / ASTM Alloy Steel / Stainless steel |
THICKNESS | View Flange Catalog |
PRESSURE RATING: | View Flange Catalog |
SEALING SURFACE | FF, RF, MFM, TG, FF |
SURFACE TREATMENT: | Anti-rust oil / Raw. |
CERTIFICATION | ISO9001:2000 , API, CE, According to Requirements |
Product Details
When is Orifice Flange used
Orifice flanges are popularly used in many industrial sectors in different applications. Heavy and light chemicals, paper industry, nuclear industry, and petrochemical industry are using these Flanges widely. These Flanges are perfectly suitable to use in sewage treatment, water treatment and distribution, power generation, and many more operations. Due to excellent performance and suitability, Orifice flanges are also ideal for applications in oil production and refining plants and gas processing and transmission.
Stainless steel orifice flanges have numerous features and specifications, which are making them perfect for any application. The ASME B16.36 standard covers flanges that are associated with those segments which are covered in standard ASME B16.5. These two standards have the only difference is that the ASME B16.36 Orifice Flange has orifice pressure differential attachments. This makes these Flanges unique from all the Flanges and also makes them able to make operation easier. These Flanges are available with all essential specifications for any industrial purpose.
The Orifice Plate Flange Offers Several Advantages
1. Stainless steel orifice flanges provides highly accurate flow measurement results.
2. Stainless steel orifice flanges structure is simple and reliable, consisting of only an orifice plate and two flanges, making it easy to install and ensuring high reliability and stability.
3. Orifice plate flanges are versatile and can be used for measuring the flow of gases, liquids, and steam in various working conditions.
4. Their simple and reliable structure also results in low maintenance costs, as parts do not require frequent repair or replacement.
5. Stainless steel orifice flanges is a dependable and precise flow measurement tool that has broad applications across various industrial fields.
Installation of Orifice Plate Flange Tips
1. Pay attention to the stainless steel orifice flanges connections and make sure they are tightened securely to prevent leakage. Use the proper tightening torque and tighten in the correct sequence.
2. Pay attention to the orientation of the orifice plate to ensure that the front of the plate faces the direction of fluid flow. The orifice plate should be orientated correctly during installation to ensure accurate flow measurement.
3. To ensure accurate flow measurement, orifice flanges require regular calibration and maintenance. Calibration can be carried out by comparison with other accurate flow meters, while maintenance includes cleaning the orifice plate, checking sealing performance and tightening bolts.
In order to ensure the correct installation of the stainless steel orifice flange and accurate flow measurement, you need more detailed installation instructions, please consult EATHU, we will give you the most professional answer!
