PIPE FITTINGS

Stainless Steel Pipe Fittings

Specification:

Stainless steel camlock

TYPE F

SIZE ITEMinch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
B22222630.738.447.56076.5103.5127.2152.4
C36.536.5425153.558.57268697479.5
D31.5323847.2546579.594.3122151176
L668090105120141





TYPE B

SIZE ITEMinch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
B50.55159717989102124149

C40.540.546.3566374.588104.7134161195
D2929.5374443.5515357575967
E14.519.8253139.550.56578.5102122.3143
L454556.5666775.283909695107


TYPE C

SIZE ITEMinch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
B515159717989102123150.5

C404046566473.587104.5134161195
D19.519.52632.339536478.7105.3130155
L8989100113.2115129148.5157.5168.5176196


TYPE D

SIZE ITEMinch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
B515159717989103.5122151161195
D29.529.53743.544515355575967
E16.219.5263640495971102146176.5
L42.542.5536463758185.59098110


TYPE E

inch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
B32.832.83746.554647792.5121.5145.5175.8
C19.819.826333952.26677.6105.5130155
D141420273244576996.5117.5141
E53.553.5636869.580.589.5101.5111117129
L9393103114118133.5144.3161.5171233248


TYPE F

SIZE ITEMinch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
A222225.2303848.56076.5104.5127.2152.4
C363641.550.552.557.558.7696772.578
D323236.746.2536477.592.5121151176
L50.551.759.5727482.58899.5105112.5122


TYPE DC

SIZE ITEMinch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
B515159.3707889101.5122.5150182215
D10.510.510.81212.81214.516161616
L3232404546535661596473


TYPE DP


SIZE ITEMinch1/2"3/4"1"1-1/4"1-1/2"2"2-1/2"3"4"5"6"
mm1520253240506580100125150
B10.510.510.511.511.313.514.513.514.51616
L25.525.5313942464850535365
